AC/DC12V 9W IP68 stainless steel rgb led swimming pool lighting led underwater lamp Dia147x123mm with over current protection

AC/DC12V 9W IP68 stainless steel rgb led swimming pool lighting led underwater lamp Dia147x123mm with over current protection
  • Продавецwww.flimmer.com
  • Список ценUS $5680.00piece
  • Продажная ценаUS $5680.00piece
  • ДоставкаБесплатная доставка
  • Рейтинги4,4 (647)

Oписание продукта


share-to-sns





HOTOOK Underwater Lights PAR56 RGB LED Swimming Pool Light Resin Filled Piscina Wall Mounted FocoPool Lamp 12V IP68 18W 42W Pond

Importante  :
​Please buy lamp , frame , and power supply separately .
1:This is 2 in one function RGB LED pool light , can be used for Par56 Recessed  and wall mounted also .
Please buy LED lamp and Fixture frame seperately !  If you don\'t have niche please buy the frame together to be used as wall mounted pool light .
2: LED Pool Lamp controlled by Switch Power On/Off to Change colors and Models .
2: No Battery in Remote to avoid Custom-Clearance problem .Battery Type: 23A 12V
3:Must Use  AC12V Power Supply (link below )  to control in Sync .
4 :LED Above-ground wall pool,Attaches to the side wall of pool.Can be easily moved to any side wall location
5: Cable Wire Default : 2m. If you have any speical request of length please contact us before buying .


PN-RCC96-1c

resin-filled




LED SWIMMING POOL LIGHT

PN-45UF18W-4PN-45UF18W-3

LED1
PN-47UF18W-16


PN-47UF18W-5
buyer-showbuyer-show1


POOLLIGHT


PN-45UF18W-16

led piscinas 18W 24W 30W 35W 42W RGB Pool Fountain Lights PAR56 12V IP68 Waterproof Underwater Synchronization Memory Fuction FreeShipping

For New Construction HOTOOK innovation and technology as the leading underwater light. It provides brighter, more vivid colors and light shows that are energy efficient, with feature rich options for pools and spas.



Product Features :

1. The lamp is filled with resin inside, which makes it 100% waterproof
2. Supports 16 different kinds of color styles
3. Amazing resin fully injected RGB resin LED PAR56 Board to replace tranditional Halogen par56
4. Super slim,good to dispel the heat,never leak,Never break,easy to install
5. Power on/off controlled
6. With Synchronized and Memory function

Applications :

 LED Swimming Pool Lights are widely used in swimming pool, spring, water view, artificial waterfall and other outdoor lightings, and can make RGB lighting effects with the remote control .

No. :

Specifications :

1

LED Type

Swimming pool led light wall mounted

2

Power

18W 24W 30W 35W 42W

3

LED Quantity

18W-252 leds; 24W-333 leds;

30W-441 leds; 35W-531 leds;

42W-630 leds;

4

Voltage

 AC 12v

5

Material

 PC

6

Lumen

18W-1620lm; 24W-2160 lm;

30W-2700lm; 35W-3150lm;

42W-3780lm ;

7

Control method

Power ON/OFF Controlled

8

Waterproof

IP68 Can put into water directly

9

Color

RGB Color changing |Red|Blue|Green|Yellow|Warm White

|Natural White, if you want to other colors, pleave leave us a message in your order!but for other colors , it takes  7-15 working days to ship out


10

Beam Angle

180 degree

11

Dimension

Φ177.2x25mm

12

use

Wall-mounted, or Embedded

13

CRI

> 88

16

Working Frequency

50 ~ 60HZ

17

Working Temperature

-40 degree ~ 60 degree

18

LED Life

> 50000 hours

19

Certificate

CE.ROHS.FCC



Instruction & Use
This is a high technology electronic controlled light based on LED’s in three colors: red, green
and blue. These three base colors together can produce many other colors to create the perfect
atmosphere in the pool. Any of the 16 pre-programmed effects can be selected with the on/off
switch of your pool lights. The LED’s can also be warm white only or natural white only. The
LED’s are driven by constant current. The technology of True PWM is adopted on the lights.
High temperature protection makes the LED’s be protected while the internal temperature
reaches a high level. All these technologies guarantee long working life of the LED lamps. Filled
fully with resin,the lights are completely waterproof ,and they must be used/operated while fully
submerged underwater only.
• This lamp is designed to be fixed in new pools and/or pools with existing lamps that need
replacement.
• This lamp is designed to be used only once. Should it become defective , repair is impossible
and replacement is necessary .
• The manufacture is not responsible in any circumstances for assembly ,installation or start-up
of any electric components which have been inserted or handled at location other than its one
premises.

16 Programs of RGB LED Bulbs
1. White: sun white
2. Red: one color red
3. Green: one color green
4. Blue: one color blue
5. Green-blue: fixed color green/blue
6. Red-green: fixed color red/green
7. Blue-red: fixed color blue-red
8. Evening sea: slow animation red/blue
9. Evening rivers: slow animation red/green
10. Riviera: slow animation green/blue
11. White: neutral white
12. Rainbow: slow animation blue/red/green
13. River of colors: program 12, followed by program 15
14. Disco: fast animation
15. Four seasons: slow animation in red/blue/green/violet
16. Party: fast animation



HTB1WQDsJVXXXXXfXpXXq6xXFXXXt



PN-37UF18W-13






Start-up
• The lamp should only be operated underwater while secured to the vertical walls of the pool ,
Never switch on the lamp if it is not underwater for long time .
• In case of colored lamps, 16 pre-programmed effects and combinations may be selected using
the on/off switch of your pool lights. Just switch off and switch on within 2 seconds.
• If the light is powered off for more than 20 seconds, it will keep the latest program when it is
turned on again.
• To achieve synchronization, confirm all lamps are installed correctly on the same switch, after
they are powered off for more than 20 seconds, switch on and switch off continuously three
times, and then finally turn them on again. They will all go to program 8. Now you can select a
program for them by switch off and on within 8 seconds.

Warnings
• Don’t use electronic transformers which may damage the light. You should use
industrial frequency transformer , such as toroidal transformer and square transformer .
• The persons who are in charge of installation should have the required qualifications for this
type of work.
• Avoid making contact with the electric voltage.
• Comply with the current standards regarding accident prevention.
• IEC 364-7-702 standards must be observed: WIRING IN BUILDINGS, SPECIAL WIRING,
SWIMMING POOLS.
• Replacement must be performed with the lamp disconnected from the electric power system.
• Do not handle any electrical components with wet feet.

Warranty
The manufacturer warrants this LED underwater light bulb against defects in materials and
workmanship for a period of two years from the date of purchase. This warranty does not cover
the fixture becoming damaged due to misuse, accidental damaged, improper handling and/or
installation and specifically excludes liability for direct, incidental or consequential damages,
water coming into the housing. Defects in materials and workmanship are exclusive of the
following:
• The light with normal LED less than 30W has 3 dead LED or less .
• The light with normal LED more than 30W (included )has 6 dead LED or less .
• The light has small air bulbs inside the resin on the front side with a size of 9mm⊃2; or less m
and the number of the air bulbs is 3 or less .
• The light has small air bulbs inside the resin on the back side .
